Accessories

Faceplate

Avalon faceplates are manufactured using fire retardant materials and are known for safety and durability. They
are available in 1 and 2 ports for different applications and usages. Each of them delivers a high speed signal for
all high speed desktop applications. They accept Cat3, Cat5e and Cat 6 UTP keystones to fit with different
performance requirements. They also perfectly blend into the decor of the home or office and protect the
network connections.
Specifications

Feature Value

UK Style with shutter
Type against dust and
labeling plate.
Polycarbonate,
I.D. Plate UL94V-2 transparent
color.
ABS, UL94V-0, with
Face plate
white color.
Dust Cover ABS, UL94V-0, with
white color
Screw M3.5XL25.0mm
Directive RoHS certified

Ordering Information
Part Number Description Dimensions

AN-WSFP-1P Flat Shutter Single Port RJ45 Faceplate, UK 86X86mm
AN-WSFP-2P Flat Shutter Dual Port RJ45 Faceplate, UK 86X86mm
AN-BVFP-86 UK Euro Angled Beveled Frame - Smooth Surface 86X86mm
AN-BVFP-50 UK Euro Single Port RJ45 Beveled Faceplate 50X25mm
AN-BVFP-50-2P UK Euro Dual Port RJ45 Beveled Faceplate 50X25mm
AN-BVA-25 Angular Keystone Adapter 25X50mm
AN-SA-25 Straight Keystone Adapter 25X50mm
AN-BA-25 Blank Adapter 25X50mm
AN-BA-12 Blank Adapter 12X50mm
................................................................................................................................................................................................................

Back Box
Avalon back boxes are manufactured using fire retardant materials and are known for safety and durability.
Each of them delivers a high speed signal for all high speed desktop applications. They also perfectly blend into
the decor of the home or office and protect the network connections.

Specifications
Feature Value

Type For UK Style Faceplate
Box ABS, UL94-HB, with white color
Screw Nut M3.5xL7.0mm
Screw M3.5X25.0x7.0 mm
Screw M3.5X19.0X7.5mm
Directive RoHS certified

Ordering Information
Part No. Description Dimensions

AN86-BB Back Box 86X86mm
