Ordering Information
Part No. Description Size Width Depth
AN-WM4U600X450 4 U x 600(W) x 450(D) Wall Mount Cabinet 4U 600mm 450mm
AN-WM6U600X450 6 U x 600(W) x 450(D) Wall Mount Cabinet 6U 600mm 450mm
AN-WM6U600X550 6 U x 600(W) x 550(D) Wall Mount Cabinet 6U 600mm 550mm
AN-WM9U600X450 9 U x 600(W) x 450(D) Wall Mount Cabinet 9U 600mm 450mm
AN-WM9U600X550 9 U x 600(W) x 550 (D) Wall Mount Cabinet 9U 600mm 550mm
AN-WM12U600X450 12 U x 600(W) x 450(D) Wall Mount Cabinet 12U 600mm 450mm
AN-WM12U600X550 12 U x 600(W) x 550(D) Wall Mount Cabinet 12U 600mm 550mm
AN-WM15U600X450 15 U x 600(W) x 450(D) Wall Mount Cabinet 15U 600mm 450mm
AN-WM15U600X550 15 U x 600(W) x 550(D) Wall Mount Cabinet 15U 600mm 550mm
AN-WM15U600X600 15 U x 600(W) x 600(D) Wall Mount Cabinet 15U 600mm 600mm
AN-WM18U600X450 18 U x 600(W) x 450(D) Wall Mount Cabinet 18U 600mm 450mm
AN-WM18U600X550 18 U x 600(W) x 550(D) Wall Mount Cabinet 18U 600mm 550mm
AN-WM18U600X600 18 U x 600(W) x 600(D) Wall Mount Cabinet 18U 600mm 600mm
Top 7 tips while buying server cabinets
1. Decide if you need an enclosed cabinet or an open Rack.
2. Assess the width, depth and height that you require depending on the equipment you will be putting
inside the Rack
3. Make a list of the equipment which would be placed in the Rack . It can include CPU, Monitors,
Keyboards, Modem, servers, Switches, Hubs, routers and UPSs etc.
4. Always ensure that you do not buy a rack that houses your equipment perfectly. Provide for future
growth by having extra space in the Rack as you would not know which equipment would be added in
the future.
5. One Rack unit (generally denoted as “U”) is 1.75’’ (4.4 cm). E.g. A 24U Rack has 24 spaces for equipment
and is 42” high (105.6 cm).
6. Measure the width, depth and height of the server room before you purchase the Rack.
7. Always ensure that there is at least 10 inches gap between the top of the Rack and the ceiling of the
room for effective ventilation.
